Tested original quality
Only genuine Kaeser replacement filter elements ensure reliable filtration with minimal pressure losses.
- Coalescence filter with matrix fibre structure
- High efficiency even at low air volumes of only five percent of nominal flow
- Reliable element-to-housing seal
- Stainless steel orifice tubes, oil & acid resistant coated sleeves and end caps
Kaeser replacement filter elements are also available as modular units for other housings.
Savings-potential with timely element changes
Timely element changes (which prevent a further differential pressure increase of 200 mbar), result in energy cost savings of €864 for a 45 kW compressor.
Calculation parameters: 6000 operating hours/year – energy price 0.20 € /kWh – 8% increase in electrical power consumption per 1 bar increase in differential pressure – compressor specific power 6.55 kW/(m³/min)
Reduce operating costs
A pressure loss of only approx. 0.35 bar is significantly more expensive than the costs required to change the filter element. Timely filter changes therefore save considerable operating costs.
